6X37+Iwr 11mm plastic coated steel wire rope for binding

Wire rope in table intensity is based on 1570N/mm2 to 1960N/mm²MBL=6 x SWLThe raw materials are supplied from GuiGang,the best in China.Providing mill CIF and other class CIF upon requestStainless tags with CIF information and company name. 6x19+FC, 6x19+IWR6x19W+FC, 6x19W+IWR6x37+FC, 6x37+IWRDiameter(mm)Tensile s

Featured Products

Wire rope in table intensity is based on 1570N/mm2 to 1960N/mm²

MBL=6 x SWL

The raw materials are supplied from GuiGang,the best in China.

Providing mill CIF and other class CIF upon request

Stainless tags with CIF information and company name.


6X37+Iwr 11mm Plastic Coated Steel Wire Rope for Lashing
6x19+FC, 6x19+IWR6x19W+FC, 6x19W+IWR6x37+FC, 6x37+IWR
Diameter(mm)Tensile strength(Mpa)Diameter(mm)Tensile strength(Mpa)Diameter(mm)Tensile strength(Mpa)
167016701670
Breaking Load WeightBreaking Load WeightBreaking Load Weight
KNKG/100mKNKG/100mKNKG/100m
6.20 24.30 13.53 8.00 44.00 24.31 8.70 47.30 26.21
7.70 38.00 21.14 9.20 59.70 32.70 11.00 74.00 40.96
9.30 54.70 30.45 11.00 80.10 43.87 13.00 106.50 58.98
11.00 74.50 41.44 12.00 100.10 54.93 15.00 145.00 80.27
12.50 97.30 54.12 13.50 126.00 69.16 17.50 189.50 104.80
14.00 123.00 68.50 14.50 151.50 82.90 19.50 239.50 132.70
15.50 152.00 84.57 16.00 183.00 100.20 21.50 296.00 163.80
17.00 184.00 102.30 17.50 217.50 119.20 24.00 358.00 198.20
18.50 219.00 121.80 19.00 250.00 137.00 26.00 426.00 235.90
20.00 257.00 142.90 20.00 278.00 152.30 28.00 500.50 276.80
21.50 298.00 165.80 21.50 320.50 175.50 30.00 580.50 321.10
23.00 342.00 190.30 22.50 360.00 197.00 32.50 666.50 368.60
24.50 389.00 216.50 24.00 408.00 223.20 34.50 758.00 419.40
26.00 439.50 244.40 25.50 452.00 247.40 36.50 856.00 473.40
28.00 492.50 274.00 27.00 505.50 276.70 39.00 959.50 530.80
31.00 608.50 338.30 30.00 613.50 335.90 43.00 1185.00 655.30
34.00 736.00 409.30 32.50 732.50 400.80 47.50 1430.00 792.90
37.00 876.00 487.10 35.00 852.50 466.40 52.00 1705.00 943.60
40.00 1025.00 571.70 38.00 1000.00 547.90 56.00 2000.00 1107.40
43.00 1190.00 663.00 40.00 1110.00 609.20 60.50 2320.00 1284.30
46.00 1365.00 761.10 ///65.00 2665.00 1474.30
6X37+Iwr 11mm Plastic Coated Steel Wire Rope for Lashing
We mainly provide lashing/cargo-securing system for General Cargo Vessel, Timber Vessel, RO-RO vessel and Container Vessel. Our products include lashing chain, ratchet belt, wire rope, shackle, D-ring, lifting beam/spreader, turnbuckle, container fitting, etc. for breakbulk, project cargo, heavy lift, logistics, transportation, marine works, port stevedoring and so on.

    If the vessel docks at Chinese ports, we can deliver our products on board within 24 hours and provide lashing service. Our service network covers most important ports all around China and we have very good relationship with those ports. In this field, we have already provided service for many world-class ship-owners such as BBC Chartering, Spliethoff, Saga Welco, etc.

    After a few years of development, in East China port rigging and lashing business, Port Star has become No. 1. We also have branches or close partners in China major port cities. Now, Port Star is not satisfied with domestic business only, our goal is to expand international market share.

    Our company has ISO9001 certification and our products are always certified by ABS, DNV, GL, LR, CCS and BV. In international market, we are still young but ambitious enough with global vision. We are looking for suitable business partners worldwide. We believe both of us can achieve a win-win future based on our integral product system, competitive price and your local marketing ability.

6X37+Iwr 11mm Plastic Coated Steel Wire Rope for Lashing
6X37+Iwr 11mm Plastic Coated Steel Wire Rope for Lashing
6X37+Iwr 11mm Plastic Coated Steel Wire Rope for Lashing
6X37+Iwr 11mm Plastic Coated Steel Wire Rope for Lashing
6X37+Iwr 11mm Plastic Coated Steel Wire Rope for Lashing
6X37+Iwr 11mm Plastic Coated Steel Wire Rope for Lashing
6X37+Iwr 11mm Plastic Coated Steel Wire Rope for Lashing
6X37+Iwr 11mm Plastic Coated Steel Wire Rope for Lashing
6X37+Iwr 11mm Plastic Coated Steel Wire Rope for Lashing
6X37+Iwr 11mm Plastic Coated Steel Wire Rope for Lashing
